MauiSails sail rigging tips


By Artur Szpunar

Downhaul (DH) measurement


Downhaul (DH) specification measured from bottom of the mast to the bottom of tack pulley.

This photo shows DH=5cm for a Mutant 4.6. Base extension must be set at next higher setting above the DH specification. For example of DH=5cm, base extension would be set at 6 or 7cm.

Boom measurement


Boom specification measured from clew to front of the mast at center of cutout.

This example shows Mutant 4.6 measuring 164cm. Sail should have between 1-2cm of positive outhaul after being fully downhauled.

Visual downhaul and outhaul check


Once downhauled and outhauled to specification, the tip of the batten above the boom should sit right at the back edge of the mast.

When rigged correctly, the sleeve should be taut, midway between the top 2 battens.

Overview







2011 Ghost XT
Side-shore light-weight wave sail

The Legend and the new Ghost-XT are both represent the highest level of refinement for wave sail performance in demanding conditions. The expressive graphic look is integrated into the whole sail body using 100% X-Ply materials, including the visibility areas, for maximum durability and crash proofing. An third graphic color makes the designs vibrant and exciting, adding the hot look that compliments the outstanding performance.

The exciting Ghost-XT range has expanded to include sizes from 4.7 to 6.7. Evolved from Legend development, the Ghost-XT incorporates similar shaping adapted to the extensive use of ultra-light and strong Technora™ scrim. The Ghost-XT offers the best in high-tech, light weight performance that you can’t imagine until you sail one.


Sail sizes : 4.7, 5.0, 5.3, 5.7, 6.1, 6.7
2011 Ghost XT  © Bogo2011 Ghost XT  © Bogo2011 Ghost XT  © Bogo2011 Ghost XT  © Bogo2011 Ghost XT  © Bogo



Check out the other MauiSails 2011 sails : Legend | Ghost XT | Global | Loco | Switch | Aloha | Pursuit | TitanGS | TR-7 | TR-7 XT | Rebel | Inspire


Sail Video Presentation

Sails Rigging Guide Movie

RAF Sails Rigging Guide
